Bootstrapping a private EKS cluster with Argo CD

A Kubernetes API server on the public internet is an attack surface most teams don’t need. In regulated environments it’s often a non-starter. EKS lets you turn the public endpoint off entirely, so the API is only reachable from inside your VPC.

That’s great for security. It’s less great for your pipeline. GitHub Actions can create the cluster, because Terraform only talks to the AWS API, which is public. But the moment you want to install something into the cluster, the runner has no route to the API server.

This post walks through building a private EKS cluster with Terraform and GitHub Actions, then getting Argo CD installed so it can take over from there. All of the code is in HeyalSolutions/eks-private-argocd-bootstrap.

The key insight: you only need to get in once

Argo CD is pull-based. It runs inside the cluster and pulls its desired state from Git. Once it’s installed, your pipeline never needs to talk to the Kubernetes API again. Changes go through pull requests, and Argo CD applies them.

So the private endpoint problem isn’t “how does CI deploy to the cluster?”. It’s “how do we install Argo CD once?”. That’s a much smaller problem.

1. GitHub Actions authenticates to AWS with OIDC and runs Terraform. Everything is created through the public AWS API.
2. The pipeline starts a CodeBuild build. CodeBuild runs inside the VPC.
3. The build installs Argo CD and one root Application.
4. Argo CD pulls everything else from Git, including its own configuration.

Step 1: let GitHub Actions into AWS (without keys)

GitHub Actions can exchange a short-lived OIDC token for AWS credentials, so there are no access keys to store or rotate. This needs an IAM OIDC provider and a role that trusts it. Both have to exist before the pipeline can run, so they live in a small bootstrap/ stack you apply once from your own machine. It also creates the S3 bucket for Terraform state.

The important part is the trust policy. Only this repository’s main branch and its pull requests can assume the role:

resource "aws_iam_openid_connect_provider" "github" {
  url            = "https://token.actions.githubusercontent.com"
  client_id_list = ["sts.amazonaws.com"]
}

data "aws_iam_policy_document" "github_trust" {
  statement {
    actions = ["sts:AssumeRoleWithWebIdentity"]

    principals {
      type        = "Federated"
      identifiers = [aws_iam_openid_connect_provider.github.arn]
    }

    condition {
      test     = "StringEquals"
      variable = "token.actions.githubusercontent.com:aud"
      values   = ["sts.amazonaws.com"]
    }

    condition {
      test     = "StringLike"
      variable = "token.actions.githubusercontent.com:sub"
      values = [
        "repo:${local.github_repo}:ref:refs/heads/main",
        "repo:${local.github_repo}:pull_request",
      ]
    }
  }
}

The example attaches AdministratorAccess to keep things short. In a real setup, scope it down and use a separate read-only role for pull request plans.

Step 2: the VPC

The VPC module does the heavy lifting. Three tiers of subnets:

• Private subnets for nodes, internal load balancers and the CodeBuild bootstrap
• Public subnets for the NAT gateway and internet-facing load balancers
• Intra subnets for the EKS control plane’s network interfaces, with no route to the internet at all

module "vpc" {
  source  = "terraform-aws-modules/vpc/aws"
  version = "~> 6.7"

  name = local.name
  cidr = local.vpc_cidr
  azs  = local.azs

  private_subnets = [for k, v in local.azs : cidrsubnet(local.vpc_cidr, 4, k)]
  public_subnets  = [for k, v in local.azs : cidrsubnet(local.vpc_cidr, 8, k + 48)]
  intra_subnets   = [for k, v in local.azs : cidrsubnet(local.vpc_cidr, 8, k + 52)]

  enable_nat_gateway = true
  single_nat_gateway = true # one per AZ in production

  public_subnet_tags  = { "kubernetes.io/role/elb" = 1 }
  private_subnet_tags = { "kubernetes.io/role/internal-elb" = 1 }
}

The NAT gateway matters here. Nodes need it to pull images, and the bootstrap build needs it to download Helm charts.

Step 3: a private EKS cluster

Version 21 of the EKS module makes the private endpoint explicit:

module "eks" {
  source  = "terraform-aws-modules/eks/aws"
  version = "~> 21.29"

  name               = local.name
  kubernetes_version = "1.35"

  endpoint_private_access = true
  endpoint_public_access  = false

  vpc_id                   = module.vpc.vpc_id
  subnet_ids               = module.vpc.private_subnets
  control_plane_subnet_ids = module.vpc.intra_subnets

  addons = {
    coredns                = {}
    kube-proxy             = {}
    eks-pod-identity-agent = { before_compute = true }
    vpc-cni                = { before_compute = true }
  }

  eks_managed_node_groups = {
    default = {
      ami_type       = "AL2023_x86_64_STANDARD"
      instance_types = ["m7i.large"]
      min_size       = 2
      max_size       = 5
      desired_size   = 2
    }
  }

  # ...access entries and security group rules, below
}

Two more pieces wire up the bootstrap. Cluster access uses access entries rather than the old aws-auth ConfigMap. The GitHub Actions role created the cluster, but it couldn’t reach it anyway, so it gets no Kubernetes permissions. Only the bootstrap build’s role does:

  enable_cluster_creator_admin_permissions = false

  access_entries = {
    bootstrap = {
      principal_arn = aws_iam_role.bootstrap.arn
      policy_associations = {
        admin = {
          policy_arn   = "arn:aws:eks::aws:cluster-access-policy/AmazonEKSClusterAdminPolicy"
          access_scope = { type = "cluster" }
        }
      }
    }
  }

  security_group_additional_rules = {
    bootstrap_https = {
      description              = "CodeBuild bootstrap to API server"
      protocol                 = "tcp"
      from_port                = 443
      to_port                  = 443
      type                     = "ingress"
      source_security_group_id = aws_security_group.bootstrap.id
    }
  }

Step 4: the pipeline

The workflow plans on pull requests and applies on main. id-token: write is what lets the job request the OIDC token:

permissions:
  id-token: write
  contents: read

jobs:
  terraform:
    runs-on: ubuntu-latest
    defaults:
      run:
        working-directory: infra
    steps:
      - uses: actions/checkout@v7

      - uses: aws-actions/configure-aws-credentials@v6
        with:
          role-to-assume: ${{ vars.AWS_ROLE_ARN }}
          aws-region: eu-west-2

      - uses: hashicorp/setup-terraform@v4
        with:
          terraform_version: 1.16.6
          terraform_wrapper: false

      - run: terraform init -input=false
      - run: terraform plan -input=false -out=tfplan

      - name: Apply
        if: github.ref == 'refs/heads/main' && github.event_name != 'pull_request'
        run: terraform apply -input=false tfplan

At this point we have a private cluster with nodes and nothing running on it. The pipeline can’t go any further on its own.

Step 5: getting in. The options

There are plenty of ways to get from a GitHub-hosted runner to a private API endpoint. Approximate us-east-1 costs, not counting the NAT gateway every option needs anyway:

Option	How it works	Pros	Cons	Rough cost
SSH jumpbox	Public EC2 instance with port 22 open; tunnel kubectl through it	Familiar, simple	Public SSH attack surface, key management, always on	~$7/month
AWS Client VPN	Runner connects to a managed VPN endpoint in the VPC	Fully AWS-managed; good for human access too	Expensive; certificate setup; an OpenVPN client in CI is fiddly	~$73/month per subnet association, plus connection hours
Tailscale (or similar)	Subnet router in the VPC; the runner joins your tailnet	Very easy; great for humans; no inbound ports	Third party in your access path; another account and auth key	Free tier, plus a ~$3/month router instance
SSM port forwarding	Instance with no inbound ports; tunnel to the API endpoint via Session Manager	No open ports; IAM-controlled; audited in CloudTrail	Standing instance; Session Manager plugin in CI; kubeconfig needs a tls-server-name override	~$3/month
Lambda in the VPC	Terraform invokes a function that runs helm install	Effectively free; pure Terraform; nothing left running	You have to package helm into the function; harder to debug; 15-minute limit	~$0
CodeBuild in the VPC	The pipeline starts a build; the buildspec runs helm inside the VPC	Effectively free; nothing left running; plain shell script; logs in CloudWatch	Another AWS service; a minute or so of start-up	~$0.02 per run

There’s also a way to skip the problem altogether: EKS Capabilities can run a managed Argo CD for you, operated by AWS and able to reach a private cluster. It’s a good fit if you’re happy for AWS to own Argo CD. It wasn’t what we wanted here, because we want Argo CD to manage itself from Git like every other component. It also needs IAM Identity Center for sign-in.

We went with CodeBuild. It ties with Lambda on cost, but there’s nothing to package: the bootstrap is a readable shell script, and the logs land in CloudWatch.

Step 6: the CodeBuild bootstrap

The CodeBuild project has no source. Its buildspec is passed in from Terraform, and it runs in the private subnets with its own security group (the one the EKS rule above allows in):

resource "aws_codebuild_project" "bootstrap" {
  name          = "${local.name}-bootstrap"
  service_role  = aws_iam_role.bootstrap.arn
  build_timeout = 20

  source {
    type      = "NO_SOURCE"
    buildspec = file("${path.module}/buildspec.yml")
  }

  artifacts {
    type = "NO_ARTIFACTS"
  }

  environment {
    type         = "LINUX_CONTAINER"
    compute_type = "BUILD_GENERAL1_SMALL"
    image        = "aws/codebuild/amazonlinux-x86_64-standard:6.0"

    environment_variable {
      name  = "CLUSTER_NAME"
      value = module.eks.cluster_name
    }
    environment_variable {
      name  = "ARGOCD_CHART_VERSION"
      value = "10.10.5"
    }
    environment_variable {
      name  = "CLUSTER_RESOURCES_REPO"
      value = local.cluster_resources_repo
    }
    environment_variable {
      name  = "DEPLOY_KEY"
      type  = "SECRETS_MANAGER"
      value = data.aws_secretsmanager_secret.deploy_key.arn
    }
  }

  vpc_config {
    vpc_id             = module.vpc.vpc_id
    subnets            = module.vpc.private_subnets
    security_group_ids = [aws_security_group.bootstrap.id]
  }
}

Its IAM role needs eks:DescribeCluster (for the kubeconfig), read access to the deploy key secret, CloudWatch Logs, and the EC2 network interface permissions CodeBuild uses to attach to the VPC. The full policy is in the repo.

The buildspec does four things: writes a kubeconfig, creates the repo credentials so Argo CD can read the private cluster-resources repo, installs Argo CD with Helm, and applies one root Application. It only does this once. If the argocd Helm release already exists, Argo CD is managing itself and a default install would fight with it:

version: 0.2

env:
  shell: bash
  variables:
    HELM_VERSION: v4.3.1
    KUBECTL_VERSION: v1.35.9

phases:
  install:
    commands:
      - curl -fsSL "https://get.helm.sh/helm-${HELM_VERSION}-linux-amd64.tar.gz" | tar -xz -C /tmp
      - install /tmp/linux-amd64/helm /usr/local/bin/helm
      - curl -fsSLo /usr/local/bin/kubectl "https://dl.k8s.io/release/${KUBECTL_VERSION}/bin/linux/amd64/kubectl"
      - chmod +x /usr/local/bin/kubectl

  build:
    commands:
      - aws eks update-kubeconfig --name "$CLUSTER_NAME"
      - kubectl get nodes

      # (writes root-app.yaml, the Application in step 7)

      - |
        set -eo pipefail
        if helm status argocd --namespace argocd >/dev/null 2>&1; then
          echo "Argo CD already installed; nothing to do."
        else
          kubectl create namespace argocd

          kubectl create secret generic cluster-resources-repo \
            --namespace argocd \
            --from-literal=type=git \
            --from-literal=url="$CLUSTER_RESOURCES_REPO" \
            --from-literal=sshPrivateKey="$DEPLOY_KEY" \
            --dry-run=client -o yaml \
            | kubectl label --local -f - argocd.argoproj.io/secret-type=repository -o yaml \
            | kubectl apply -f -

          helm upgrade --install argocd argo-cd \
            --repo https://argoproj.github.io/argo-helm \
            --version "$ARGOCD_CHART_VERSION" \
            --namespace argocd \
            --wait --timeout 10m

          kubectl apply -f root-app.yaml
        fi

Back in the workflow, a second job starts the build through the AWS API and waits for it:

  bootstrap:
    needs: terraform
    if: github.ref == 'refs/heads/main' && github.event_name != 'pull_request'
    runs-on: ubuntu-latest
    steps:
      - uses: aws-actions/configure-aws-credentials@v6
        with:
          role-to-assume: ${{ vars.AWS_ROLE_ARN }}
          aws-region: eu-west-2

      - name: Bootstrap Argo CD
        env:
          PROJECT: ${{ needs.terraform.outputs.bootstrap_project }}
          LOG_GROUP: ${{ needs.terraform.outputs.bootstrap_log_group }}
        run: |
          build_id=$(aws codebuild start-build --project-name "$PROJECT" --query 'build.id' --output text)

          while true; do
            status=$(aws codebuild batch-get-builds --ids "$build_id" --query 'builds[0].buildStatus' --output text)
            [ "$status" != "IN_PROGRESS" ] && break
            sleep 15
          done

          # CodeBuild names the log stream after the build ID (the part after the colon)
          aws logs tail "$LOG_GROUP" --log-stream-name-prefix "${build_id#*:}" --since 1h || true

          if [ "$status" != "SUCCEEDED" ]; then
            echo "::error::Bootstrap build finished with status $status"
            exit 1
          fi

It runs on every push to main, but thanks to the guard it’s a no-op once Argo CD is installed. It costs a couple of cents, and a brand new cluster gets bootstrapped automatically.

Step 7: Argo CD manages itself

The root Application points at the cluster-resources repo, a Helm chart whose templates are themselves Argo CD Applications (the “app of apps” pattern):

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: cluster-resources
  namespace: argocd
spec:
  project: default
  source:
    repoURL: git@github.com:my-org/cluster-resources.git
    targetRevision: main
    path: .
  destination:
    server: https://kubernetes.default.svc
    namespace: argocd
  syncPolicy:
    automated:
      prune: true
      selfHeal: true

One of those templates is an Application for Argo CD itself. It uses the same chart and the same release name (argocd) as the bootstrap install, so it adopts the resources Helm created rather than creating new ones:

apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: argocd
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://argoproj.github.io/argo-helm
    chart: argo-cd
    targetRevision: {{ .Values.argocd.chartVersion | quote }}
    helm:
      releaseName: argocd
      valuesObject:
        {{- toYaml .Values.argocd.values | nindent 8 }}
  destination:
    server: https://kubernetes.default.svc
    namespace: argocd
  syncPolicy:
    automated:
      prune: true
      selfHeal: true
    syncOptions:
      - ServerSideApply=true # Argo CD's CRDs are too big for client-side apply

From here on, Argo CD’s configuration lives in cluster-resources/values.yaml. Upgrading Argo CD is a pull request that bumps chartVersion. Every other add-on (cert-manager, ingress controllers, external-secrets, monitoring) is another template in the same chart, following the same pattern.

Things to watch out for

• Keep the bootstrap chart version in step. The bootstrap installs ARGOCD_CHART_VERSION, and Git then says what it should be. If they drift, a new cluster briefly runs the older version until Argo CD syncs itself.
• The bootstrap guard is load-bearing. Without it, every pipeline run would reinstall Argo CD with default values and fight with the self-managed configuration.
• Humans still need a way in. CI doesn’t need cluster access any more, but people sometimes do. SSM port forwarding or a VPN (from the table above) works well for break-glass kubectl, with its own access entry.
• Use a deploy key or GitHub App for Argo CD. It should have read-only access to cluster-resources. The example stores a deploy key in Secrets Manager, created by the one-time bootstrap/ stack so it exists before the first run.

Wrapping up

A private EKS endpoint doesn’t have to mean self-hosted runners, VPNs in CI or a bastion you have to babysit. Because GitOps is pull-based, you only need to get inside the VPC once, and a CodeBuild build started from the pipeline does that for a couple of cents. After that, Git is the only way changes reach the cluster.

The full example, including the IAM policies and the cluster-resources chart, is at HeyalSolutions/eks-private-argocd-bootstrap.
